90 horsepower EFI

Power tilt & trim

Forward Control

HDEF90FVEL-T RRP $16,980

HDEF90FVEX-T RRP $17,180

L - long shaft

X - extra long shaft

Forward control models come with surface mount control box, control cable, selector cables, fuel/water separator filter and fixings. Multi-function gauge optionally available.

24L fuel tank standard.

HDF90 EFI – EFI advanced technology

In addition to the usual great features and finishes found on the 4-stroke models, the big block 4-cylinder 90HP EFI has the following benefits.

Electronic Fuel Injection (EFI) system

The Programmed Electronic Fuel Injection (EFI) utilises the DELPHI ECU system that accurately controls ignition timing during start up, providing optimum overall operation, with instant throttle response and fuel efficient performance.

More Quiet

HDEF90 EFI features quiet operation due to being a power 4-cylinder 4-stroke motor using the Reverse Exhaust Relief system, redirecting exhaust gas through propeller in the water.

Quick Starts

The Electronic Fuel Injection (EFI) system, automatically adjusts the air-fuel mixture for quick, easy starting and warming-up.

Engine Alert System

Engine Alert System, it constantly monitors vital engine functions and reduces the likelihood of damage by alerting the driver of overheating, low oil pressure and other critical engine functions.

Power Thrust Design.

The HDEF90 EFI are using a higher gear ratio to provide these engines with extraordinary forward and reverse thrust for improved maneuverability and performance.

Cruising Fuel Economy

The EFI system automatically adjusts the air-fuel mix according to speed and load, this maximizes power throughout the RPM range will save up to 20% less fuel than other comparably sized outboards in the cruise speed.

NMEA2000 compatible

Plug and play NMEA2000 compatibility.

HDF90 EFI 4-Stroke Benefits:

◇ Actual six layers of paint, good corrosion resistance.

◇ Using the US brand PPG paint, more beautiful exterior.

◇ Plus timer, maintenance more convenient.

◇ Sleek design

◇ Light and compact!

◇ Advanced cross-flow induction for smooth operation

◇ Larger capacity oil reservoir for optimum lubrication

◇ Tuned intake system for crisp takeoffs

◇ CE approved.

High Performance and Easy Operation:

◇ Digital CD ignition for easier engine starting, quicker throttle response and smoother trolling

◇ Recoil starter with larger reel making manual starting fast and easy

◇ Large alternator and rectifier for superior battery charging

◇ Front mounted shift lever for easier operation

◇ Remote control models available

◇ Shallow water drive

◇ Adjustable steering friction for reducing steering effort

Fundamentals for User Convenience and Reliability:

◇ Through-the-prop exhaust for a quieter ride

◇ Thermostatically controlled cooling system for consistent engine temperature

◇ Stainless steel water pump housing liner for outstanding durability

◇ High grade marine aluminum alloy that provides the ultimate protection against corrosion

◇ Zinc coating on internal water passages for superior corrosion resistance

◇ 24 litre fuel tank including fuel fittings and fuel line

◇ Aluminum propeller

90HP (66.2kW)

HDEF90
